Danfoss VLT AutomationDrive FC 301 Programming Manual page 245

Parameter Descriptions
15-10 Logging Source
Option: Function:
[1616] Torque [Nm]
[1617] Speed [RPM]
[1618] Motor Thermal
[1620] Motor Angle
[1621] Torque [%]
High Res.
[1622] Torque [%]
[1624] Calibrated
Stator
Resistance
[1625] Torque [Nm]
High
[1628] Angle Error This option is only available for
software version 48.XX
[1630] DC Link
Voltage
[1632] Brake
Energy /s
[1633] Brake Energy
Average
[1634] Heatsink
Temp.
[1635] Inverter
Thermal
[1645] Motor Phase U
Current
[1646] Motor Phase V
Current
[1647] Motor Phase
W Current
[1648] Speed Ref.
After Ramp
[RPM]
[1650] External
Reference
[1651] Pulse
Reference
[1652] Feedback[Unit]
[1657] Feedback
[RPM]
[1660] Digital Input
[1662] Analog Input
53
[1664] Analog Input
54
[1665] Analog Output
42 [mA]
[1666] Digital Output
[bin]
[1675] Analog In
X30/11
[1676] Analog In
X30/12
M0013101
Programming Guide
15-10 Logging Source
Option:
[1677]
[1687]
[1689]
[1690]
[1692]
[1694]
[1695]
[1697]
[1698]
[1820]
[1821]
[1823]
[1827]
[1828]
[1829]
[1840]
[1841]
[1842]
[1843]
[1844]
[1845]
[1846]
[1860]
[3110]
[3466]
[3470]
[3471]
Danfoss A/S © 10/2019 All rights reserved.
Function:
Analog Out
X30/8 [mA]
Bus Readout
Alarm/Warning
Configurable
Alarm/Warning
Word
Alarm Word
Warning Word
Ext. Status
Word
Ext. Status
Word 2
Alarm Word 3
Warning Word
3
Commanded
Position
Master
Position
Virtual Master
Pos.
Safe Opt. Est.
Speed
Safe Opt.
Meas. Speed
Safe Opt.
Speed Error
Analog Input
X49/1
Analog Input
X49/3
Analog Input
X49/5
Analog Out
X49/7
Analog Out
X49/9
Analog Out
X49/11
X49 Digital
Output [bin]
Digital Input 2
Bypass Status
Word
SPI Error
Counter
MCO Alarm
Word 1
MCO Alarm
Word 2
3 3
