Parameter Descriptions
8-54 Reversing Select
Select the trigger for the reversing function.
Option: Function:
[1] Bus A serial communication port or the
fieldbus triggers the reversing
function.
[2] Logic AND The fieldbus/serial communication
port and a digital input trigger the
reversing function.
[3] Logic OR The fieldbus/serial communication
port or a digital input triggers the
reversing function.
8-55 Set-up Select
Select the trigger for the set-up selection.
Option: Function:
[0] Digital input A digital input triggers the set-up
selection.
[1] Bus A serial communication port or the
fieldbus triggers the set-up
selection.
[2] Logic AND The fieldbus/serial communication
port and a digital input trigger the
set-up selection.
[3] Logic OR The fieldbus/serial communication
*
port or a digital input triggers the
set-up selection.
8-56 Preset Reference Select
Option: Function:
Select the trigger for the preset
reference selection.
[0] Digital input A digital input triggers the preset
reference selection.
[1] Bus A serial communication port or the
fieldbus triggers the preset
reference selection.
[2] Logic AND The fieldbus/serial communication
port and a digital input trigger the
preset reference selection.
[3] Logic OR The fieldbus/serial communication
*
port or a digital input triggers the
preset reference selection.
8-57 Profidrive OFF2 Select
Select control of the frequency converter OFF2 selection via the
terminals (digital input) and/or via the fieldbus. This parameter is
active only when parameter 8-01 Control Site is set to [0] Digital
and ctrl. word and parameter 8-10 Control Word Profile is set to [1]
PROFIdrive profile.
Option: Function:
[0] Digital input
M0013101
Programming Guide
8-57 Profidrive OFF2 Select
Select control of the frequency converter OFF2 selection via the
terminals (digital input) and/or via the fieldbus. This parameter is
active only when parameter 8-01 Control Site is set to [0] Digital
and ctrl. word and parameter 8-10 Control Word Profile is set to [1]
PROFIdrive profile.
Option:
[1]
[2]
[3]
*
8-58 Profidrive OFF3 Select
Select control of the frequency converter OFF3 selection via the
terminals (digital input) and/or via the fieldbus. This parameter is
active only when parameter 8-01 Control Site is set to [0] Digital
and ctrl. word, and parameter 8-10 Control Word Profile is set to
[1] PROFIdrive profile.
Option:
[0]
[1]
[2]
[3]
*
3.9.6 8-8* FC Port Diagnostics
These parameters are used for monitoring the bus
communication via the frequency converter RS485 port
terminals 68-69.
8-80 Bus Message Count
Range:
0
*
8-81 Bus Error Count
Array [6]
Range:
0
*
8-82 Slave Messages Rcvd
Range:
0
*
8-83 Slave Error Count
Range:
0
*
Danfoss A/S © 10/2019 All rights reserved.
Function:
Bus
Logic AND
Logic OR
Function:
Digital input
Bus
Logic AND
Logic OR
Function:
[0 - 0 ] This parameter shows the number
of valid telegrams detected on the
bus.
Function:
[0 - 0 ] This parameter shows the number
of telegrams with faults (for
example CRC fault) detected on the
bus.
Function:
[0 - 0 ] This parameter shows the number
of valid telegrams addressed to the
slave sent by the frequency
converter.
Function:
[0 - 0 ] This parameter shows the number
of error telegrams, which are not
3 3
