Parameter Description

3.14 Parameters: 16-** Data Readouts

3.14.1 16-0* General Status
3 3
16-00 Control Word
Range:
0 [0 - 65535] View the control word sent from the frequency
*
16-01 Reference [Unit]
Range:
0 ReferenceFeed-
backUnit
*
16-02 Reference [%]
Range:
0 % [-200 -
*
200 %]
16-03 Status Word
Range:
0 [0 - 65535] View the status word sent from the frequency
*
16-05 Main Actual Value [%]
Range:
0 % [-100 - 100 %] View the 2-byte word sent with the status
*
16-09 Custom Readout
Range:
0 CustomRea-
doutUnit
*
118
VLT
Function:
converter via the serial communication port in
hex code.
Function:
[-999999 - View the present reference
999999 value applied on impulse or
ReferenceFeed- analog basis in the unit
backUnit] resulting from the configu-
ration selected in
parameter 1-00 Configu-
ration Mode (Hz, Nm, or
RPM).
Function:
View the total reference. The total reference
is the sum of digital, analog, preset, bus,
and freeze references, plus catch up and
slow down.
Function:
converter via the serial communication port in
hex code.
Function:
word to the fieldbus master reporting the
main actual value.
Function:
[-999999.99 - View the user-defined readouts
999999.99 as defined in
CustomRea- parameter 0-30 Custom Readout
doutUnit] Unit, parameter 0-31 Custom
Readout Min Value, and
parameter 0-32 Custom Readout
Max Value.
Danfoss A/S © 05/2016 All rights reserved.
®
Refrigeration Drive FC 103
3.14.2 16-1* Motor Status
16-10 Power [kW]
Range:
0 kW [0 -
*
1000
kW]
16-11 Power [hp]
Range:
0 hp [0 -
*
1000 hp]
16-12 Motor Voltage
Range:
0 V [0 - 6000 V] View the motor voltage, a calculated value
*
16-13 Frequency
Range:
0 Hz [0 - 6500 Hz] View the motor frequency, without
*
16-14 Motor current
Range:
0 A [0 - 1856
*
A]
16-15 Frequency [%]
Range:
0 % [-100 -
*
100 %]
Function:
Shows motor power in kW. The value shown is
calculated based on the actual motor voltage
and motor current. The value is filtered, and
therefore approximately 1.3 s may pass from
when an input value changes to when the data
readout values change. The resolution of
readout value on fieldbus is in 10 W steps.
Function:
View the motor power in hp. The value shown
is calculated based on the actual motor
voltage and motor current. The value is
filtered, and therefore approximately 1.3 ms
may pass from when an input value changes
to when the data readout values change.
Function:
used for controlling the motor.
Function:
resonance damping.
Function:
View the motor current measured as an
average value, I . The value is filtered, and
RMS
thus approximately 1.3 s may pass from when
an input value changes to when the data
readout values change.
Function:
View a 2-byte word reporting the actual motor
frequency (without resonance damping) as a
percentage (scale 0000–4000 hex) of
parameter 4-19 Max Output Frequency. Set
parameter 9-16 PCD Read Configuration index 1
to send it with the status word instead of the
MAV.
