Danfoss VLT AutomationDrive FC 301 Programming Manual page 95

Parameter Descriptions
3-19 Jog Speed [RPM]
Range: Function:
Size [ 0 - par. 4-13 Enter a value for the jog speed
related RPM] n
*
JOG
The frequency converter runs at
this speed when the jog function is
activated. The maximum limit is
defined in parameter 4-13 Motor
Speed High Limit [RPM].
See also parameter 3-80 Jog/Homing
Ramp Time.
3.4.3 3-2* References II
3-20 Preset Target
Range: Function:
NOTICE
0 Custom- [-2147483648
ReadoutUni - 2147483647
This parameter is only
t2 CustomRea-
*
available with software version
doutUnit2]
48.XX.
Array [8]
Set up to 8 target positions. Select
from the 8 preset positions using
digital inputs or the fieldbus control
word.
3-21 Touch Target
Range: Function:
NOTICE
0 Custom- [-2147483648
ReadoutUni - 2147483647
This parameter is only
t2 CustomRea-
*
available with software version
doutUnit2]
48.XX.
Enter the target position in touch
probe positioning mode. This
parameter defines the distance
from the detection event of the
touch probe sensor to the final
target position in position units.
3-22 Master Scale Numerator
Range: Function:
NOTICE
1 [-2147483648
*
-
This parameter is only
2147483647 ]
available with software version
48.XX.
Parameter 3-22 Master Scale
Numerator and
parameter 3-23 Master Scale
Denominator define the gear ratio
between the master and the slave
M0013101
Programming Guide
, which is a fixed output speed.
Danfoss A/S © 10/2019 All rights reserved.
3-22 Master Scale Numerator
Range: Function:
in synchronization mode.
Master revolutions =
× Slave revolutions
3-23 Master Scale Denominator
Range: Function:
NOTICE
1 [-2147483648
*
-
This parameter is only
2147483647 ]
available with software version
48.XX.
See parameter 3-22 Master Scale
Numerator.
3-24 Master Lowpass Filter Time
Range: Function:
NOTICE
20 ms [1 - 2000 ms]
*
This parameter is only
available with software version
48.XX.
Enter the time constant for master
speed calculation in synchronizing
mode.
3-25 Master Bus Resolution
Range: Function:
NOTICE
65536 [128 -
*
2147483647 ]
This parameter is only
available with software version
48.XX.
Enter the resolution of the fieldbus
master signal (fieldbus Sync Ref ) in
synchronization mode.
3-26 Master Offset
Range: Function:
NOTICE
0 Custom- [-2147483648
ReadoutUni - 2147483647
This parameter is only
t2 CustomRea-
*
available with software version
doutUnit2]
48.XX.
Enter the position offset between
the master and the slave in
synchronization mode. This value is
added to the follower position at
each activation of a digital input
with option [113] Enable Reference
or bit 5 of the fieldbus control
Par . 3 − 22
Par . 3 − 23
3 3
