32-Bit Arm ® Cortex ® -M3 MCU
HT32F12345

Register Descriptions

Flash Target Address Register – TADR
This register specifies the target address of the page erase and word programming operations.
Offset: 0x000
Reset value: 0x0000_0000
31
Type/Reset RW 0 RW
23
Type/Reset RW 0 RW
15
Type/Reset RW 0 RW
7
Type/Reset RW 0 RW
Bits Field
[31:0] TADB
Rev. 1.10
30 29 28
0 RW 0 RW
22 21 20
0 RW 0 RW
14 13 12
0 RW 0 RW
6 5 4
0 RW 0 RW
Descriptions
Flash Target Address Bits
For programming operations, the TADR register specifies the address where the
data is written. Since the programming length is 32-bit, the TADR should be set
as word-aligned (4 bytes). The TADB [1:0] will be ignored during programming
operations. For page erase operations, the TADR register contains the page
address which is going to be erased. Since the page size is 1 KB, the TADB [9:0]
will be ignored in order to limit the target address as 1 KB-aligned. For 64 KB
main Flash addressing, TADB [31:16] should be zero. The Option Byte which has
a 1 KB capacity ranges from 0x1FF0_0000 to 0x1FF0_03FF. This field is used to
specify the Flash address which must be within the range from 0x0000_0000 to
0x1FFF_FFFF. Otherwise, an Invalid Target Address interrupt will be generated if
the corresponding interrupt enable bit is set.
53 of 590
27 26
TADB
0 RW 0 RW 0 RW
19 18
TADB
0 RW 0 RW 0 RW
11 10
TADB
0 RW 0 RW 0 RW
3 2
TADB
0 RW 0 RW 0 RW
25 24
0 RW 0
17 16
0 RW 0
9 8
0 RW 0
1 0
0 RW 0
November 28, 2018
