32-Bit Arm ® Cortex ® -M3 MCU
HT32F12345

PDMA Request

The EBI only supports using a software trigger for active PDMA service.

Register Map

The following table shows the EBI register and reset value.

Table 68. Register Map of EBI

Register
EBI Base Address = 0x4009_8000
EBICR
EBIPCR
EBISR
EBIATR0
EBIRTR0
EBIWTR0
EBIPR0
EBIATR1
EBIRTR1
EBIWTR1
EBIPR1
EBIATR2
EBIRTR2
EBIWTR2
EBIPR2
EBIATR3
EBIRTR3
EBIWTR3
EBIPR3
EBIIENR
EBIIFR
EBIIFCR
Rev. 1.10
Offset
0x000 EBI Control Register
0x004 EBI Page Control Register
0x008 EBI Status Register
0x010 EBI Address Timing Register 0
0x014 EBI Read Timing Register 0
0x018 EBI Write Timing Register 0
0x01C EBI Parity Register 0
0x020 EBI Address Timing Register 1
0x024 EBI Read Timing Register 1
0x028 EBI Write Timing Register 1
0x02C EBI Parity Register 1
0x030 EBI Address Timing Register 2
0x034 EBI Read Timing Register 2
0x038 EBI Write Timing Register 2
0x03C EBI Parity Register 2
0x040 EBI Address Timing Register 3
0x044 EBI Read Timing Register 3
0x048 EBI Write Timing Register 3
0x04C EBI Parity Register 3
0x050 EBI Interrupt Enable Register
0x054 EBI Interrupt Flag Register
0x058 EBI Interrupt Clear Register
527 of 590
Description Reset Value
0x0000_0000
0x0000_0F00
0x0000_0010
0x0000_0F0F
0x000F_3F0F
0x000F_3F0F
0x0000_0000
0x0000_0F0F
0x000F_3F0F
0x000F_3F0F
0x0000_0000
0x0000_0F0F
0x000F_3F0F
0x000F_3F0F
0x0000_0000
0x0000_0F0F
0x000F_3F0F
0x000F_3F0F
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
November 28, 2018
