Features

▄
16 system Cortex
▄
Up to 64 Maskable peripheral interrupts
▄
16 programmable priority levels (4 bits for interrupt priority setting)
▄
Non-Maskable interrupt
▄
Low-latency exception and interrupt handling
▄
Vector table remapping capability
▄
Integrated simple, 24-bit system timer, SysTick
● 24-bit down counter
● Auto-reloading capability
● Maskable system interrupt generation when counter decrements to 0
● SysTick clock source derived from the HCLK or AHB clock divided by 8

Functional Descriptions

SysTick Calibration

The SysTick Calibration Value Register (SCALIB) is provided by the NVIC to give a reference time
base of 1 ms for the RTOS tick timer or other purpose. The TENMS field in the SCALIB register
has a fixed value of 12000 which is the counter reload value to indicate 1 ms when the clock source
comes from the SysTick reference input clock STCLK with a frequency of 12 MHz (96 MHz divide
by 8).

Register Map

The following table shows the NVIC registers and reset values.

Table 27. NVIC Register Map

Register
NVIC Base Address = 0xE000_E000
ICTR
SCTRL
SLOAD
SVAL
SCALIB
ISER0_31
ISER32_63
ISER64_95
ICER0_31
ICER32_63
ICER64_95
ISPR0_31
ISPR32_63
ISPR64_95
ICPR0_31
ICPR32_63
Rev. 1.10
-M3 exceptions
®
Offset
0x004 Interrupt Control Type Register
0x010 SysTick Control and Status Register
0x014 SysTick Reload Value Register
0x018 SysTick Current Value Register
0x01C SysTick Calibration Value Register
0x100 Irq 0 to 31 Set Enable Register
0x104 Irq 32 to 63 Set Enable Register
0x108 Irq 64 to 95 Set Enable Register
0x180 Irq 0 to 31 Clear Enable Register
0x184 Irq 32 to 63 Clear Enable Register
0x188 Irq 64 to 95 Clear Enable Register
0x200 Irq 0 to 31 Set Pending Register
0x204 Irq 32 to 63 Set Pending Register
0x208 Irq 64 to 95 Set Pending Register
0x280 Irq 0 to 31 Clear Pending Register
0x284 Irq 32 to 63 Clear Pending Register
169 of 590
Description Reset Value
0x0000_0001
0x0000_0000
Unpredictable
Unpredictable
0x4000_2EE0
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
