32-Bit Arm ® Cortex ® -M3 MCU
HT32F12345
I 2 S Rate Counter Value Register – I2SRCNTR
This register specifics the I 2 S rate control counter value.
Offset : 0x01C
Reset value: 0x0000_0000
31
Type/Reset
23
Type/Reset
15
Type/Reset RW 0 RW
7
Type/Reset RW 0 RW
Bits Field
[19:0] RCNTR
Rev. 1.10
30 29 28
22 21 20
Reserved
14 13 12
0 RW 0 RW
6 5 4
0 RW 0 RW
Descriptions
Rate Counter Value
This value must be equal to or higher than Y_DIV for useful rate fine-tuning
control.
558 of 590
27 26
Reserved
19 18
RW 0 RW 0 RW
11 10
RCNTR
0 RW 0 RW 0 RW
3 2
RCNTR
0 RW 0 RW 0 RW
25 24
17 16
RCNTR
0 RW 0
9 8
0 RW 0
1 0
0 RW 0
November 28, 2018
