Danfoss iC7 Series Application Manual page 75

Application Guide | iC7 Series Industry
A pressure transducer to measure the pressure of the system. This data is used as feedback. The sensor is supplied power by the
l
drive's 24 V supply.
A potentiometer to adjust the setpoint, and a switch for the start signal which is connected to digital input 1 (terminal 13) on the
l
Basic I/O. See the following wiring drawing example.
Feedback
Pressure Transmitter
P
Reference
Potentiometer
Figure 55: Wiring diagram example - Process Control with Basic I/O
1. Perform all the steps in
2. Perform all the steps in
3.
Perform all the steps in
4.
Select the process controller as reference in the settings for the control place.
Index
5.5.6.2.6
5.5.6.2.7
5.
Adjust settings for the process reference and for the feedback according to the application. In this example, the operating range
is 0–4 bar.
© 2024.05
11 (24V)
12 (24V)
13 (DI1)
Start
14 (DI2)
Forward
15 (DI/DO1)
16 (DI/DO2)
Coast
17 (DI3)
Inverse
18 (DI4)
19 (GND)
20 (GND)
31 (AO1)
32 (+ 10V)
33 (AI1)
34 (AI2)
35 (GND)
5.2 Basic Setup of a Drive.
5.3 Configuring the Motor, Motor Control, and Motor Thermal
5.4 Configuring Speed Control.
Parameter name
Adv. Process Reference
Adv. Process Reference Logic
Protection.
Recommended settings
Fieldbus reference/Reference 1 input
Source 1
AB480436531518en-000601 / 136R0283 |
Configuration Set-up Examples
Parameter
number
6054
6045
