Selection Number Selection Name
0 None
1 Sine-wave Filter
P 3.5.2 Filter Capacitance
Set the capacitance of the output filter.
Default Value: \*
Parameter 5502
Number:
Data Type: REAL
Set the Cy (capacitance) value of the output filter. See the filter product label for the capacitance value. The value is the equivalent star-
connected capacitance of the filter. When the filters are installed in parallel, enter the combined capacitance value of the paralleled filter.
The value is the equivalent star-connected capacitance (Cy) of the filter multiplied by the number of installed paralleled filters.
P 3.5.3 Filter Inductance
Set the inductance of the output filter.
Default Value: \*
Parameter 5503
Number:
Data Type: REAL
Set the inductance of the output filter. See the product label of the filter for the value of inductance. When filters are installed in parallel,
enter the combined inductance value of the installed paralleled filters. The inductance value in the parameter is the inductance value of
the filter divided by the number of paralleled filters.

Motor (Menu Index 4)

6.5

Motor Overview

6.5.1
This parameter group contains parameters for configuring the motor, motor control, and motor protection.

Motor Status (Menu Index 4.1)

6.5.2
P 4.1.1 Motor Current
Shows the actual motor current.
Default Value: NA
Parameter
9000
Number:
Data Type: REAL
P 4.1.2 Relative Motor Current
Shows the actual motor current in % of the nominal motor current.
© 2024.05
Selection Description
No output filter connected.
Sine-wave filter connected.
Parameter Type:
Unit:
Access Type:
Parameter Type:
Unit:
Access Type:
Parameter Type:
Unit:
Access Type:
AB480436531518en-000601 / 136R0283 |
Parameter Descriptions
Range (0.00 — 1000000.00)
μF
Read/Conditional Write
Range (0.00 — 1000.00)
mH
Read/Conditional Write
Range (0 — \*)
A
Read Only
109
