Table 14: Asynchronous Induction Motors
Index
4.2.3.1
4.2.3.2
4.2.3.3
4.2.3.4
4.2.3.5
4.2.3.6
Table 15: Permanent Magnet Motors
Index
4.2.4.2
4.2.4.3
4.2.4.4
4.2.4.5
4.2.4.6
4.2.4.7
4.2.4.8
4.2.4.1
4.
Configure motor control.
68 | © 2024.05
Parameter name
Stator Resistance Rs
Rotor Resistance Rr
Iron Loss Resistance Rfe
Stator Leakage Reactance Xls
Rotor Leakage Resistance Xlr
Magnetizing Reactance Xm
Parameter name
Stator Resistance Rs
d-axis Inductance Ld
d-axis Inductance LdSat
Ld Saturation Point
q-axis Inductance Lq
q-axis Inductance LqSat
Lq Saturation Point
Back EMF
Parameter setting
Result of AMA or as on motor data
sheet.
Result of AMA or as on motor data
sheet.
Result of AMA or as on motor data
sheet.
Result of AMA or as on motor data
sheet.
Result of AMA or as on motor data
sheet.
Result of AMA or as on motor data
sheet.
Parameter setting
Result of AMA or as on motor product
label.
Result of AMA or as on motor product
label.
Result of AMA or as on motor product
label.
Result of AMA or as on motor product
label.
Result of AMA or as on motor product
label.
Result of AMA or as on motor product
label.
Result of AMA or as on motor product
label.
Only for Permanent Magnet Motors.
as on motor data sheet, as specified at
1000 RPM.
