Application Guide | iC7 Series Industry
Table 12: Datalogger Settings Fields
Field name
Storage
Trigger position (s)
Trigger type
Trigger level 1
© 2024.05
(continued)
Field description
Select the location to which datalogger files are stored.
Available selections are:
• RAM: Settings are stored to the RAM of the drive.
• Flash: Settings are stored to the flash of the drive.
• SD card: Data is stored on the (optional) microSD card.
The microSD cards supported are: SD, SDHC, or SDXC which
must be formatted for the FAT32 file system. SDHC is the rec-
ommended type, because they are delivered preformatted
to FAT32.
Adjust the slider to position the trigger. Setting the trigger
position to 0 indicates the datalogger recording starts at
the time of the trigger. Setting a negative value indicates
that the datalogger recording starts after the trigger has oc-
curred. Setting a positive value indicates that the datalogger
recording starts before the trigger has occurred.
Following are the trigger types:
• No trigger (manual trigger only).
• Equal triggers when the value of the trigger source
variable is equal to trigger level 1.
• Not equal triggers when the value of the trigger source
variable is not equal to trigger level 1.
• Greater than triggers when the value of the trigger source
variable is greater than trigger level 1.
• Greater than or equal to triggers when the value of the
trigger source variable is greater than or equal to trigger
level 1.
• Less than triggers when the value of the trigger source
variable is less than trigger level 1.
• Less than or equal to triggers when the value of the
trigger source variable is less than or equal to trigger level
1.
• Rising edge triggers when the value of the trigger source
variable rises above trigger level 1. If the trigger source is
already above trigger level 1, the trigger must first drop
below the trigger level.
• Falling edge triggers when the value of the trigger source
variable falls below trigger level 1. If the trigger source
is already below trigger level 1, the trigger must first rise
above the trigger level.
Defines the trigger level associated with the defined trigger
type. This level is used for all single-level trigger types. The
entry in the field defines the lower trigger level for window
trigger types, such as bounds and out of bounds.
AB480436531518en-000601 / 136R0283 |
User Interfaces
53
