Figure 27: Parameters (Live)
1
Parameter group: Navigate through the different
parameter groups in the drive.
3 Value field: View and change a parameter value
or selection. All the parameters for the drive are
shown on the Live screen.
5 Favorites: Select a parameter as a favorite by
clicking the star in its row. Open the favorites
panel on the right side of the screen by clicking
the star at the top of the page.
3.
Navigate through the parameter groups.
a. Click the parameter group (1) from the Live pane.
b.
Click the parameter subgroup (2).
c.
Repeat step 2 until the right level of parameter sub group (3) is reached to find the specific parameters (4).
© 2024.05
2
1
4
3
2
Search field: Use the search function to find a
specific parameter.
4 PC Control button: Switch to PC control to start or
stop the drive using MyDrive® Insight.
