Application Guide | iC7 Series Industry
Figure 22: Connection to the PC
1 Ethernet switch
2.
When the drive is powered up and in Ready state, open MyDrive® Insight on the device and the drive is recognized.
3. To establish or confirm the connection, click the arrow button.
Figure 23: Confirm Connection

Once the connection is established, the drive is marked with a green connection symbol in MyDrive® Insight.
Figure 24: Connection Established
4. To interact with the drive, navigate to the required screen in MyDrive® Insight. The example picture shows the Device Info
screen.
© 2024.05
1
AB480436531518en-000601 / 136R0283 |
User Interfaces
45
