Danfoss iC7 Series Application Manual page 351

Application Guide | iC7 Series Industry
Table 56: Summary Table
(continued)
Group Numb Display Name
Numb er
er (Deci
(Hex) mal)
0x32F 4147 DC-link Voltage Ripple
F
0x32F 4148 DC-link Imbalance
F
0x411 4099 Ambient Temp. High
0
0x421 4107 Brake Chopper Temp.
0 Limit
0x421 4108 Brake Chopper Temp.
0 High 1
0x421 4109 Brake Chopper Temp.
0 High 2
0x422 4106 Brake Chopper Temp. Low
0
0x428 5132 Temp. Protection 1
0
© 2024.05
Description
Excessive voltage ripple has been detected
on the main DC-link capacitors. This can be
caused by an imbalance of the grid. Reduce
the output power.
An imbalance across the DC-link capacitors is
detected. The imbalance can be caused by a
component fault of the DC link. If the fault re-
mains after resetting the drive, service is re-
quired.
The ambient temperature is too high. Check
the temperature and cooling conditions.
Lower the temperature or improve the cool-
ing conditions.
The temperatute of the brake chopper heat
sink is at the upper limit of the normal tem-
perature range. Check cooling and heat sink
conditions. Reduce the generated regenera-
tive power.
The temperature of the brake chopper heat
sink has exceeded the normal temperature
range. Check cooling and heat sink condi-
tions. Reduce the generated regenerative
power.
The temperature of the brake chopper heat
sink has reached a critical level. Check cooling
and heat sink conditions. Reduce the gener-
ated regenerative power.
The temperature of the brake chopper heat
sink is too low. Check the ambient temper-
ature. Increase the ambient temperature or
consider an external heater to increase the
temperature around the drive.
Temperature protection 1 is triggered. The
temperature has exceeded the configured
value.
Troubleshooting
Type of Event Inverter and
Brake Chopper
Action
I F P Invert
W F er
X X C
X X C
X
X
X X C
X X C
X X C
X X RC
AB480436531518en-000601 / 136R0283 |
Brake
C
C
C
351
