Selection Number Selection Name
3 OR
4 NAND
5 NOR
6 XOR
7 XNOR
P 5.5.6.1.3 Advanced Start Backward Input
Select inputs for starting in the backward direction when operating in advanced control.
Default Value: –
Parameter 4725
Number:
Data Type:
UINT
P 5.5.6.1.4 Advanced Start Backward Logic
Select the combination logic for the start-backward command of advanced control.
Default Value:
0 (Source 1)
Parameter 1934
Number:
Data Type:
UINT
The following are the selections for the parameter.
Selection Number Selection Name
0 Source 1
1 Source 2
2 AND
3 OR
4 NAND
5 NOR
6 XOR
7 XNOR
P 5.5.6.1.5 Advanced Stop Inverse Input
Select inputs for stopping when operating in advanced control. False means the drive is stopped.
Default Value: –
© 2024.05
Selection Description
Logically OR source 1 and 2.
Logically NAND source 1 and 2.
Logically NOR source 1 and 2.
Logically XOR source 1 and 2.
Logically XNOR source 1 and 2.
Parameter Type:
Unit:
Access Type:
Parameter Type:
Unit:
Access Type:
Selection Description
Use value from source 1 only.
Use value from source 2 only.
Logically AND source 1 and 2.
Logically OR source 1 and 2.
Logically NAND source 1 and 2.
Logically NOR source 1 and 2.
Logically XOR source 1 and 2.
Logically XNOR source 1 and 2.
Parameter Type:
AB480436531518en-000601 / 136R0283 |
Parameter Descriptions
Selection
–
Read/Write
Selection
–
Read/Write
Selection
