Danfoss iC7 Series Application Manual page 356

Application Guide | iC7 Series Industry
Table 56: Summary Table
(continued)
Group Numb Display Name
Numb er
er (Deci
(Hex) mal)
0x43F 4126 IGBT Temperature Imbal-
F ance
0x43F 4127 IGBT Temperature Imbal-
F ance
0x43F 4131 Temperature Imbalance
F Brake IGBT
0x43F 4132 IGBT temperature delta
F
0x448 5400 AHF High Temp. Derate
0
0x448 5401 AHF High Temp. Stop
0
0x510 4208 Service Mode Exit
0
0x510 4641 24V Backup Mode
0
0x510 4803 Service Mode Active
0
0x511 4640 24V Supply Fault
2
0x511 4642 3.3V Supply Low
4
0x511 4643 28V Supply Low
8
0x51F 4644 Gate Driver Voltage Fault
E
0x51F 4653 Gate Driver Fault
E
0x51F 4645 Power Board Supply Fault
F
356 | © 2024.05
Description
There is a temperature imbalance between 1
or more IGBT's.
An excessive thermal imbalance between the
IGBT modules has been detected. Check the
condition of IGBT modules their connections
the cooling and the driver boards.
There is a temperature imbalance between 1
or more brake chopper IGBT's.
There is a temperature imbalance between 1
or more IGBT's.
A too high temperature is detected in the
connected AHF (Advanced Harmonic Filter).
Output is derated to 50%.
A too high temperature has been detected in
the connected AHF (Advanced Harmonic Fil-
ter). Operation of the drive is stopped.
Drive has left service mode. Power cycle is re-
quired to reset the drive.
The drive is in 24V backup mode. The control
section (including parameter configurations)
and installed options are kept operational.
Drive is in service mode.
The 24V supply is outside its normal operat-
ing range.
The voltage of the internal 3.3V supply is be-
low its normal operating range.
The voltage of the internal 28V supply is be-
low its normal operating range.
The gate driver supply voltage is outside its
normal operating range.
A gate driver fault is detected or a link to the
gate driver is broken.
A power supply fault on the power board has
been detected.
Troubleshooting
Type of Event Inverter and
Brake Chopper
Action
I F P Invert
W F er
X
X
X X C
X X C
X
X RC
X C
X
X
X C
X C
X C
X C
X C
X C
AB480436531518en-000601 / 136R0283
Brake
C
C
C
C
C
C
C
C
C
