Table 56: Summary Table
(continued)
Group Numb Display Name
Numb er
er (Deci
(Hex) mal)
0x712 4382 Blocked Rotor
0
0x712 5200 AMA Active
0
0x712 5201 AMA Motor Data
0
0x712 5202 AMA Motor Type
0
0x712 5203 AMA Successful
0
0x712 5300 Invalid Motor Data
0
0x712 5600 Feedback Test Active
0
0x712 5601 Feedback Test Successful
0
0x712 5602 Feedback Resolution/
0 Poles High
0x712 5603 Feedback Resolution/
0 Poles Low
0x712 5606 Feedback Unstable
0
0x712 4182 Motor Sync Loss
2
0x72F 4417 Feedback Option Fault
F
0x730 4207 Sensor Configuration
0
0x731 4418 Bad Speed Feedback
0
© 2024.05
Description
The rotor is blocked.
The AMA (Automatic Motor Adaptation) is ac-
tive. Normal run of the motor is not possible.
Apply a start signal to run the AMA.
The motor data measurement of the AMA
(Automatic Motor Adaptation) was unsuc-
cessful.
The motor type detection of the AMA (Auto-
matic Motor Adaptation) was unsuccessful.
The AMA (Automatic Motor Adaptation) was
performed successfully.
Invalid motor data is preventing operation.
Check the motor data settings.
Normal running is suppressed for a motor
feedback test run.
The motor feedback test was able to verify
the motor feedback signal.
Feedback signal was slower than expected.
Feedback signal was faster than expected.
Feedback signal was inconsistent.
Select the drive response if the synchroniza-
tion between motor and drive is lost. This is
only relevant when using a permanent mag-
net or synchronous reluctance motor.
The Feedback Option is indicating a fault con-
dition.
A sensor configuration error has been de-
tected. A sensor is either missing, not ex-
pected, or incorrectly connected.
Speed Feedback value is not reliable.
Troubleshooting
Type of Event Inverter and
Brake Chopper
Action
I F P Invert
W F er
X X C
X
X C
X C
X
X X C
X
X
X C
X C
X C
X X C
X C
X RC
X C
AB480436531518en-000601 / 136R0283 |
Brake
C
C
C
C
C
C
