Application Guide | iC7 Series Industry
Selection Number Selection Name
9049 L2-L3 Line Voltage (RMS)
9050 L3-L1 Line Voltage (RMS)
9047 Grid Voltage Imbalance
P 8.3.3.5 Status Value 1.5
Select the parameter for status value 1.5.
Default Value:
0 (None)
Parameter 304
Number:
Data Type: UDINT
The following are the selections for the parameter.
Selection Number Selection Name
0 None
1 Actual Control Value
2 Automatic Reference
9011 Motor Speed
9000 Motor Current
9010 Motor Shaft Speed
9009 Motor Torque
1708 Relative Motor Torque
9005 Motor Voltage
9008 Motor Shaft Power
674 Load Drooping Speed
666 Estimated Inertia
6075 Process Controller Output
6090 Feedback Value
1718 Speed Reference
6092 Setpoint Value
6151 Final Speed Reference
6153 Control Panel Speed Reference
306 | © 2024.05
Selection Description
Shows the L2-L3 line voltage (RMS).
Shows the L3-L1 line voltage (RMS).
Shows the grid voltage imbalance in %. A value greater than 3%
may indicate grid problems.
Parameter Type:
Unit:
Access Type:
Selection Description
Nothing selected.
Shows the reference depending on operation mode.
Shows the actual motor speed.
Shows the actual motor current.
Shows the shaft speed in RPM.
Shows the actual motor torque.
Shows the motor torque in % of the nominal motor torque.
Shows the actual motor voltage.
Shows the actual power at the motor shaft.
Shows the load drooping speed.
Shows the process controller's output as normalized value (in the
range 0 to 1).
Shows the actual value of the feedback.
Shows the speed reference.
Shows the actual value of the setpoint.
Shows the value of the speed reference before feeding it to the
speed controller.
Shows the value of the speed reference given from the control
panel.
Parameter Descriptions
Selection
–
Read/Write
