Application Guide | iC7 Series Industry
Ethernet Interface X1/X2 Settings (Menu Index 10.2.3)
6.11.2.3
Interface X1/X2 IPv4 Settings
6.11.2.3.1
The Ethernet Interface X1/X2 IPv4 settings view contains the following fields:
Interface X1 MAC address
l
IPv4 addressing method
l
Requested IPv4 address
l
Requested IPv4 SUBNET mask
l
Requested IPv4 gateway address
l
Enable ACD
l
DNS server 1
l
DNS server 2
l
Interface X1/X2 IPv4 Status
6.11.2.3.2
The Ethernet Interface X1/X2 IPv4 status view contains the following fields:
Interface X1 MAC address
l
IPv4 addressing method
l
Actual IPv4 address
l
Actual IPv4 SUBNET mask
l
Actual IPv4 gateway address
l
DHCP server
l
Actual DNS server 1
l
Actual DNS server 2
l
ACD activity
l
Ethernet port X0 (Menu Index 10.2.4)
6.11.2.4
X0 Settings (Menu Index 10.2.4.2)
6.11.2.4.1
P 10.2.4.2.5 Link configuration X0
Select the configuration of the Ethernet link parameters.
Default Value:
0 (Auto negotiation)
Parameter 7047
Number:
Data Type: USINT
The following are the selections for the parameter.
Selection Number Selection Name
0 Auto negotiation
1 10 Mbps full duplex
2 10 Mbps half duplex
3 100 Mbps full duplex
4 100 Mbps half duplex
338 | © 2024.05
Parameter Type:
Unit:
Access Type:
Selection Description
The drive handles the speed and duplex settings.
10 Mbps with full duplex.
10 Mbps with half duplex.
100 Mbps with full duplex.
100 Mbps with half duplex.
Parameter Descriptions
Selection
–
Read/Write
AB480436531518en-000601 / 136R0283
