Danfoss iC7 Series Application Manual page 175

Application Guide | iC7 Series Industry
Selection Number Selection Name
0 Source 1
1 Source 2
2 AND
3 OR
4 NAND
5 NOR
6 XOR
7 XNOR
P 5.5.6.1.9 Advanced Reversing Input
Select inputs for inverting the reference signal when operating in advanced control. The reverse command does not provide a start
signal.
Default Value: –
Parameter
4730
Number:
Data Type: UINT
P 5.5.6.1.10 Advanced Reverse Logic
Select the combination logic for the reverse command of advanced control.
Default Value: 3 (OR)
Parameter
1937
Number:
Data Type: UINT
The following are the selections for the parameter.
Selection Number Selection Name
0 Source 1
1 Source 2
2 AND
3 OR
4 NAND
5 NOR
6 XOR
7 XNOR
© 2024.05
Selection Description
Use value from source 1 only.
Use value from source 2 only.
Logically AND source 1 and 2.
Logically OR source 1 and 2.
Logically NAND source 1 and 2.
Logically NOR source 1 and 2.
Logically XOR source 1 and 2.
Logically XNOR source 1 and 2.
Parameter Type:
Unit:
Access Type:
Parameter Type:
Unit:
Access Type:
Selection Description
Use value from source 1 only.
Use value from source 2 only.
Logically AND source 1 and 2.
Logically OR source 1 and 2.
Logically NAND source 1 and 2.
Logically NOR source 1 and 2.
Logically XOR source 1 and 2.
Logically XNOR source 1 and 2.
AB480436531518en-000601 / 136R0283 |
Parameter Descriptions
Selection
–
Read/Write
Selection
–
Read/Write
175
