Danfoss iC7 Series Application Manual page 55

Application Guide | iC7 Series Industry
Table 12: Datalogger Settings Fields
Field name
Trigger source
Signals
3. Click Apply Settings.
© 2024.05
(continued)
Field description
Click the Trigger sourcefield to select the signal source which
is used for triggering the datalogger recording. The trigger
source list opens in a new window:
Figure 35: Trigger Source List
Click the Add signal button under the Signalsheading. A Sig-
nalfield appears. Click the Signal field to select the signals
that are logged. The signal list opens in a new window:
Figure 36: Signals List
AB480436531518en-000601 / 136R0283 |
User Interfaces
55
