Danfoss iC7 Series Application Manual page 139

Application Guide | iC7 Series Industry
Table 39: Motor Regulator Status Word bit descriptions
Bit Description
0 Current limit control active (motoring side).
1 Current limit control active (generator side).
2 Torque limit control active (motoring side).
3 Torque limit control active (generator side).
4 Overvoltage control active.
5 Undervoltage control active.
6 Power limit control active (motoring side).
7 Power limit control active (generator side).
8 Speed limit control active.
9 AC-brake control active.
P 5.1.5 Fault Status Word 1
Shows the fault status word 1.
Default Value: Parameter Type:
Parameter
6203
Number:
Data Type: DWORD
Table 40: Fault Status Word 1 bit descriptions
Bit Description
0 Overcurrent
1 Overvoltage
2 Undervoltage
3 Unit temperature high
4 Unit temperature low
5 Control board overtemperature
6 Input phase
7 Output phase
8 Ground fault
9 Fan failure
10 Fieldbus communication
11 HMI connection
© 2024.05
Range (\* — \*)
Unit:
Access Type:
Event number
4384, 4373, 5170, 4368, 4369, 4375, 4377, 4380, 4097
4164, 4162, 4144 4145
4165, 4146
4117, 4118, 4119
4116
4121, 4122, 4123, 4120
4160, 4163
4175, 4176
4379, 4352, 4353, 4354, 4355
4128, 4129, 4133, 4130
5162, 4256, 4257, 4258, 4260, 4261, 4263, 4265,
4266 ,4267, 4268, 4269, 4280, 4281, 4270, 4271, 4272,
4273, 4282, 4274, 4275, 4276, 4277, 4283, 4278, 4279
5141, 5142
AB480436531518en-000601 / 136R0283 |
Parameter Descriptions
–
–
139
