Table 43: Status Word Description
Bit Bit Name
Number
0 Enabled
1 Start
2 Brake open feedback signal
3 Brake close feedback
4–10 N/A
11 Priming
12 Brake release timeout
13 Brake close timeout
14 BrakeCtrl active
15 Brake open
P 5.12.1.2 Mechanical Brake State
Shows the state of the mechanical brake controller.
Default Value:
NA
Parameter 3017
Number:
Data Type: INT
P 5.12.1.3 Brake Release Time Detected
Shows the time from brake release until load change is detected, where motor takes over the load from mechanical brake.
Default Value: NA
Parameter
3041
Number:
Data Type: REAL
6.6.13.3 Brake Settings (Menu Index 5.12.2)
P 5.12.2.1 Brake Output
Select the output terminal for controlling the mechanical brake.
Default Value:
–
Parameter 3007
Number:
Data Type:
UINT
252 | © 2024.05
Description
Mechanical brake is enabled by a parameter.
A start signal is provided to mechanical brake control.
Brake feedback is enabled and brake open is active.
Brake feedback is enabled and brake closed is active.
The required release torque could not be generated.
Feedback is enabled but brake open feedback was not provided during brake
release time.
Feedback is enabled but brake close feedback was not provided during brake
close time.
Brake control is either in progress of opening or closing brake.
Brake control has activated digital output.
Parameter Type:
Unit:
Access Type:
Parameter Type:
Unit:
Access Type:
Parameter Type:
Unit:
Access Type:
Parameter Descriptions
Range (0 — 32767)
–
Read Only
Range (0 — 10000)
s
Read Only
Selection
–
Read/Write
