Application Guide | iC7 Series Industry
Data Type: UINT
The following are the selections for the parameter.
Selection Number Selection Name
0 Speed control
1 Torque control
21 Process control
P 5.4.2.20 Rotational Direction Limit
Sets the limit for directional rotation of the motor.
Default Value: 0 (Both Directions)
Parameter 2501
Number:
Data Type:
UINT
The following are the selections for the parameter.
Selection Number Selection Name
0 Both Directions
1 Clockwise Only
2 Counter Clockwise Only
Control Places (Menu Index 5.5)
6.6.6
Control Places Overview
6.6.6.1
The parameters of parameter group 5.5are used to configure the source from where the drive receives its commands, and what types
of references are used. The configuration of the reference sources is part of the application controller parameterization. Commands and
references are configured per operation mode of the drive (see also parameter 5.4.2.16). The Industry application software supports the
following control places:
Local control through the Control Panel
l
Fieldbus control
l
I/O control
l
Advanced control
l
Advanced control allows the logical combination of 2 command sources.
The supported command logic for Advanced control is:
Source 1
l
Source 2
l
© 2024.05
Access Type:
Selection Description
The drive controls the motor speed.
The drive controls the motor torque.
The drive controls a process variable based on feedback to the
process controller.
Parameter Type:
Unit:
Access Type:
Selection Description
Allow the motor to spin both clockwise and counterclockwise.
Allow the motor to only run in clockwise direction with a positive
reference. The minimum reference will be set to 0.
The motor is only allowed to run in counterclockwise direction
with a negative reference. Maximum reference will be set to 0.
AB480436531518en-000601 / 136R0283 |
Parameter Descriptions
Read/Write
Selection
–
Read/Write
