Table 47: Fault Status Word 1 bit descriptions
Bit Description
0 Overcurrent
1 Overvoltage
2 Undervoltage
3 Unit temperature high
4 Unit temperature low
5 Control board overtemperature
6 Input phase
7 Output phase
8 Ground fault
9 Fan failure
10 Fieldbus communication
11 HMI connection
12 Feedback connection
13 Thermistor input
14 Auxiliary device (temperature)
15 External temperature measurement
P 5.1.8 Warning Status Word 1
Shows the warning status word 1.
Default Value: Parameter Type:
Parameter 6205
Number:
Data Type:
DWORD
Table 48: Warning Status Word 1 bit descriptions
Bit Description
0 Overcurrent
1 Overvoltage
2 Undervoltage
3 Unit temperature high
4 Unit temperature low
5 Control board overtemperature
© 2024.05
Event number
4384, 4373, 5170, 4368, 4369, 4375, 4377, 4380, 4097
4164, 4162, 4144 4145
4165, 4146
4117, 4118, 4119
4116
4121, 4122, 4123, 4120
4160, 4163
4175, 4176
4379, 4352, 4353, 4354, 4355
4128, 4129, 4133, 4130
5162, 4256, 4257, 4258, 4260, 4261, 4263, 4265,
4266 ,4267, 4268, 4269, 4280, 4281, 4270, 4271, 4272,
4273, 4282, 4274, 4275, 4276, 4277, 4283, 4278, 4279
5141, 5142
4418
5157
4200, 4201, 4203, 4202
5132, 5133, 5134, 5135, 5136, 5137, 5158
Range (\* — \*)
Unit:
Access Type:
Event number
4384, 4373, 5170, 4368, 4369, 4375, 4377, 4380, 4097
4164, 4162, 4144 4145
4165, 4146
4117, 4118, 4119
4116
4121, 4122, 4123, 4120
