Danfoss iC7 Series Application Manual page 352

Application Guide | iC7 Series Industry
Table 56: Summary Table
(continued)
Group Numb Display Name
Numb er
er (Deci
(Hex) mal)
0x428 5133 Temp. Protection 2
0
0x428 5134 Temp. Protection 3
0
0x428 5135 Temp. Protection 4
0
0x428 5136 Temp. Protection 5
0
0x428 5137 Temp. Protection 6
0
0x428 5158 Motor Temperature
0
0x428 5157 Motor Thermistor
1
0x42F 4200 Power Option Temp. High
F 1
0x42F 4201 Power Option Temp. High
F 2
0x42F 4202 Power Option Temp. Low
F
0x42F 4203 Power Option Temp. Limit
F
352 | © 2024.05
Description
Temperature protection 2 is triggered. The
temperature has exceeded the configured
value.
Temperature protection 3 is triggered. The
temperature has exceeded the configured
value.
Temperature protection 4 is triggered. The
temperature has exceeded the configured
value.
Temperature protection 5 is triggered. The
temperature has exceeded the configured
value.
Temperature protection 6 is triggered. The
temperature has exceeded the configured
value.
The analog temperature sensor has exceeded
the configured value.
The motor thermistor is too hot.
The temperature of a power option has ex-
ceeded the normal temperature range. Check
the cooling conditions. Reduce the load or
the ambient temperature.
The temperature of a power option has
reached a critical level. Check the cooling
conditions. Reduce the load or the ambient
temperature.
The temperature of a power option compo-
nent is to low. Check the ambient tempera-
ture. Increase the ambient temperature or
consider an external heater to increase the
temperature around the power option.
The temperature of a power option compo-
nent is at the upper limit of the normal tem-
perature. Check the cooling conditions. Re-
duce the load or the ambient temperature.
Troubleshooting
Type of Event Inverter and
Brake Chopper
Action
I F P Invert
W F er
X X RC
X X RC
X X RC
X X RC
X X RC
X X RC
X C
X X RC
X X RC
X X RC
X
AB480436531518en-000601 / 136R0283
Brake
C
C
C
C
