Backing up the Drive

3.3.7.2
1. To back up the drive, select a drive, go to Setup & Services > Parameters.
2. Click the backup destination icon shown in the following figure.
Figure 40: Backup Destination icon

A screen to select the backup destination opens. The destinations to back up are:
Project: The user can back up an existing project or a new project.
¢
Device file system: The user can back up to 1 of the available memory devices of the drive.
¢
3. Click Next.
4.
This step depends on the backup destination selection:
a.
If Project was selected, give the backup file a name and description.
b. If Device file system was selected, select where to save the backup. The selections are flash, RAM, or an (optional) microSD
card. It is possible to specify a name for the backup file as well.
5.
Click Backup to begin backup.

Once backup is completed, a notification screen about it appears. If a Project backup was created, the backup is shown in the
device menu under Parameters.
