Danfoss iC7 Series Application Manual page 140

Application Guide | iC7 Series Industry
Table 40: Fault Status Word 1 bit descriptions
Bit Description
12 Feedback connection
13 Thermistor input
14 Auxiliary device (temperature)
15 External temperature measurement
P 5.1.8 Warning Status Word 1
Shows the warning status word 1.
Default Value: Parameter Type:
Parameter
6205
Number:
Data Type: DWORD
Table 41: Warning Status Word 1 bit descriptions
Bit Description
0 Overcurrent
1 Overvoltage
2 Undervoltage
3 Unit temperature high
4 Unit temperature low
5 Control board overtemperature
6 Input phase
7 Output phase
8 Ground fault
9 Fan failure
10 Fieldbus communication
11 HMI connection
12 Feedback connection
13 Thermistor input
14 Auxiliary device (temperature)
15 External temperature measurement
140 | © 2024.05
(continued)
Range (\* — \*)
Unit:
Access Type:
Event number
4418
5157
4200, 4201, 4203, 4202
5132, 5133, 5134, 5135, 5136, 5137, 5158
–
–
Event number
4384, 4373, 5170, 4368, 4369, 4375, 4377, 4380, 4097
4164, 4162, 4144 4145
4165, 4146
4117, 4118, 4119
4116
4121, 4122, 4123, 4120
4160, 4163
4175, 4176
4379, 4352, 4353, 4354, 4355
4128, 4129, 4133, 4130
5162, 4256, 4257, 4258, 4260, 4261, 4263, 4265,
4266 ,4267, 4268, 4269, 4280, 4281, 4270, 4271, 4272,
4273, 4282, 4274, 4275, 4276, 4277, 4283, 4278, 4279
5141, 5142
4418
5157
4200, 4201, 4203, 4202
5132, 5133, 5134, 5135, 5136, 5137, 5158
AB480436531518en-000601 / 136R0283
Parameter Descriptions
