Selection lists with inputs and/or outputs consist of the name of the hardware option and the numbers of the
NOTE:
terminals. For example, terminal number 13 of the Basic I/O is called Basic I/O T13 in the selection list.

Basic Setup of a Drive

5.2
The basic setup of the drive consists of the following configuration steps.
1. Configure the grid settings.
Index
1.2.1
2. Configure the power unit settings.
Index
2.2.1.1
2.2.1.2
3. Configure the operating mode.
Index
5.4.2.16
5.4.2.19
4.
Configure the control place settings.
Index
5.5.2.1
5.5.3.1.2
5.5.6.1.1
5.5.6.1.2
5.5.6.1.7
5.5.6.1.8
5. Configure the fieldbus communications (if available). See the relevant fieldbus guide.
6. Configure the readouts in the control panel. See Understanding Readout Screens.
66 | © 2024.05
Parameter name
Grid Type
Parameter name
Unit Voltage Class
Overload Mode
Parameter name
Operation Mode
Motor Feedback Mode
Parameter name
Control Place Selection
Local Control Mode
Advanced Start Input
Advanced Start Logic
Advanced Coast Inverse Input
Advanced Coast Inverse Logic
Example setting
TN
Example setting
Low-voltage range
High overload (HO1)
Example setting
Speed control
Open loop
Example setting
Advanced control
Allow local control
Fieldbus start, Basic I/O T13
Source 1
Fieldbus coast, Basic I/O T16
Source 1
AB480436531518en-000601 / 136R0283
Configuration Set-up Examples
Parameter
number
2942
Parameter
number
2832
2833
Parameter
number
2500
2502
Parameter
number
114
107
4722
1933
4724
1936
