Danfoss iC7 Series Application Manual page 307

Application Guide | iC7 Series Industry
Selection Number Selection Name
6155 Local Torque Reference
9007 Feedback Speed
9044 DC-link Voltage
9041 Grid Frequency
9040 Line-To-Line Voltage (RMS)
9048 L1-L2 Line Voltage (RMS)
9049 L2-L3 Line Voltage (RMS)
9050 L3-L1 Line Voltage (RMS)
9047 Grid Voltage Imbalance
Status Screen 2 (Menu Index 8.3.4)
6.9.4.4
P 8.3.4.1 Status Value 2.1
Select the parameter for status value 2.1.
Default Value: 9010 (Motor Shaft Speed)
Parameter 310
Number:
Data Type:
UDINT
The following are the selections for the parameter.
Selection Number Selection Name
0 None
1 Actual Control Value
2 Automatic Reference
9011 Motor Speed
9000 Motor Current
9010 Motor Shaft Speed
9009 Motor Torque
1708 Relative Motor Torque
9005 Motor Voltage
9008 Motor Shaft Power
674 Load Drooping Speed
666 Estimated Inertia
© 2024.05
Selection Description
Shows the local torque reference set in the control panel.
Shows the feedback speed.
Shows the actual DC-link voltage.
Shows the actual grid frequency.
Shows the average line-to-line voltage (RMS).
Shows the L1-L2 line voltage (RMS).
Shows the L2-L3 line voltage (RMS).
Shows the L3-L1 line voltage (RMS).
Shows the grid voltage imbalance in %. A value greater than 3%
may indicate grid problems.
Parameter Type:
Unit:
Access Type:
Selection Description
Nothing selected.
Shows the reference depending on operation mode.
Shows the actual motor speed.
Shows the actual motor current.
Shows the shaft speed in RPM.
Shows the actual motor torque.
Shows the motor torque in % of the nominal motor torque.
Shows the actual motor voltage.
Shows the actual power at the motor shaft.
Shows the load drooping speed.
AB480436531518en-000601 / 136R0283 |
Parameter Descriptions
Selection
–
Read/Write
307
