Blocked Rotor Detection (Menu Index 5.2.6) - Danfoss iC7 Series Application Manual

Application Guide | iC7 Series Industry
Parameter 5229
Number:
Data Type: UINT
The following are the selections for the parameter.
Selection Number Selection Name
3 Warning
9 Fault, ramp to coast
10 Fault

Blocked Rotor Detection (Menu Index 5.2.6)

6.6.3.4
Use the blocked rotor detection function to detect if the rotor is blocked by the application. This feature can protect the motor or
application and identify if something is preventing the drive from ramping up the motor to the desired speed reference. If the motor
is running in either torque or current limit for the set detection time, the blocked rotor function triggers an event. The function only is
active in the speed range from 0 up to the set blocked rotor maximum speed.
P 5.2.6.1 Blocked Rotor Response
Select how the drive responds when detecting a blocked rotor.
Default Value: 0 (No response)
Parameter 2370
Number:
Data Type:
UINT
The following are the selections for the parameter.
Selection Number Selection Name
0 No response
3 Warning
1 Fault
P 5.2.6.2 Blocked Rotor Max. Speed
Set the maximum speed for checking for a blocked rotor.
Default Value:
10
Parameter 2371
Number:
Data Type: REAL
P 5.2.6.3 Blocked Rotor Detection Time
Set the duration that the rotor can be blocked before a response is triggered.
© 2024.05
Unit:
Access Type:
Selection Description
The drive issues a warning.
Issues a fault, ramps down, and coast.
The drive issues a fault and coasts the motor.
Parameter Type:
Unit:
Access Type:
Selection Description
The event is ignored.
The drive issues a warning.
The drive issues a fault and coasts the motor.
Parameter Type:
Unit:
Access Type:
AB480436531518en-000601 / 136R0283 |
Parameter Descriptions
–
Read/Write
Selection
–
Read/Write
Range (0 — 100)
Hz
Read/Write
151
