B2.18 CCSIDR_EL1, Cache Size ID Register, EL1
The CCSIDR_EL1 provides information about the architecture of the currently selected cache.
Bit field descriptions
CCSIDR_EL1 is a 32-bit register, and is part of the Identification registers functional group.
This register is Read Only.
WT, [31]
WB, [30]
RA, [29]
WA, [28]
NumSets, [27:13]
100798_0300_00_en
31 30 29 28 27
WT WA
WB
RA
Indicates whether the selected cache level supports Write-Through:
Cache Write-Through is not supported at any level.
0
For more information about encoding, see
Indicates whether the selected cache level supports Write-Back. Permitted values are:
Write-Back is not supported.
0
Write-Back is supported.
1
For more information about encoding, see
Indicates whether the selected cache level supports read-allocation. Permitted values are:
Read-allocation is not supported.
0
Read-allocation is supported.
1
For more information about encoding, see
Indicates whether the selected cache level supports write-allocation. Permitted values are:
Write-allocation is not supported.
0
Write-allocation is supported.
1
For more information about encoding, see
(Number of sets in cache) - 1. Therefore, a value of 0 indicates one set in the cache. The number
of sets does not have to be a power of 2.
For more information about encoding, see
Copyright © 2016–2018 Arm Limited or its affiliates. All rights

B2.18 CCSIDR_EL1, Cache Size ID Register, EL1

NumSets
Figure B2-14 CCSIDR_EL1 bit assignments
