A7.3 Support for memory types
The Cortex-A76 core simplifies the coherency logic by downgrading some memory types.
• Memory that is marked as both Inner Write-Back Cacheable and Outer Write-Back Cacheable is
cached in the L1 data cache and the L2 cache.
• Memory that is marked Inner Write-Through is downgraded to Non-cacheable.
• Memory that is marked Outer Write-Through or Outer Non-cacheable is downgraded to Non-
cacheable, even if the inner attributes are Write-Back cacheable.
The following table shows the transaction capabilities of the Cortex-A76 core. It lists the maximum
possible values for read, write, DVM issuing, and snoop capabilities of the private L2 cache.
Attribute
Write issuing capability
Read issuing capability
Snoop acceptance capability
DVM issuing capability
100798_0300_00_en
Value
22/34/46
22/34/46
17/23/29
22/34/46
Copyright © 2016–2018 Arm Limited or its affiliates. All rights
reserved.
Non-Confidential

A7.3 Support for memory types

Table A7-1 Cortex-A76 Transaction Capabilities
Description
Maximum number of outstanding write
transactions. Dependent on the configured
TQ size. (24/36/48)
Maximum number of outstanding read
transactions. Dependent on the configured
TQ size. (24/36/48)
Maximum number of outstanding snoops
and stashes accepted. Dependent on the TQ
size. (24/36/48)
Maximum number of outstanding DVMOp
transactions. Dependent on the configured
TQ size. (24/36/48)
