Confirm the Results of the Cutting Test

Confirm the cutting test results, and adjust to optimal setting. Repeat cutting test and adjustment until optimal cut
is achieved.
Adjustment of Offset
Check the corners of the triangles and rectangles. See "Setting the
Tool"
and adjust the offset value if the corner is not cut
P.2-38
or if it is cut too much.
Adjust offsets in Normal mode.
Adjustment for Half Cutting
Peel off the triangle area, and adjust so it cuts slightly into the
backing sheet.
If the backing sheet has been cut through, either the FORCE setting
is too high or the cutter-blade tip is extended too far. If the backing
sheet shows only a few traces of the cutter blade, either the FORCE
setting is too low or the cutter blade tip is not sufficiently extended.
Adjustment for Cutting Out
Adjust so the media is completely cut out.
If the media is not completely cut, either the FORCE setting is too low or the cutter blade tip is not sufficiently
extended.
See "Adjusting the Blade Length"
Adjustment When Using Plotting Pen
Adjust the FORCE so there will be no faint lines. To prolong the pen life, set the FORCE to the lowest setting
without any faint lines. See"Setting the Force"
and "Setting the Force"
P.2-2
or setting the FORCE.
P.2-41
2-47
Supplement
How to check offset
Check if the offset value is set correctly by
following.
Not enough adjustment.
Increase the offset value.
Optimal offset value.
Too much adjustment.
Decrease the offset value.
Supplement
See "Adjusting the Blade Length"
and "Setting the Force"
the settings.
and adjust the settings.
P.2-41
P.2-2
and adjust
P.2-41
