CDM-570/570L Satellite Modem with Optional IP Module
Ethernet-based Remote Product Management
1. For proper SNMP operation, use the CDM-570/570L MIB files with the
2. For SNMP access via the Ethernet M&C port, configure the CDM-570/570L

6.4.1 Management Information Base (MIB) Files

MIB files are used for SNMP remote management of a unique device. A MIB file consists of a
tree of nodes called Object Identifiers (OIDs). Each OID provides remote management of a
particular function. These MIB files should be compiled in a user-supplied MIB Browser or
SNMP Network Monitoring System server. The following MIB files are associated with the
CDM-570/570L:
MIB File/Name (where 'X'
indicates the revision letter)
FW10874-2X.mib
ComtechEFData MIB file
FW10874-3X.mib
IP Module MIB file
FW10874-4X.mib
CDM-570/570L MIB file
FW10874-5X.mib
CDM-570/570L Traps MIB file
FW10874-6X.mib
CDM-570L BUC/LNB MIB file
FW10874-7X.mib
CDM-570L L-Band BUC/LNB
Traps MIB file
FW10874-8X.mib
CSAT-5060 MIB file
FW10874-9X.mib
KST-2000A/B MIB file
associated version of the CDM-570/570L modem M&C and the IP Module
SW. See the CDM-570/570L FW Release Notes for information on the
required FW/SW compatibility.
via SELECT: CONFIG
Description
ComtechEFData MIB file gives the root tree for ALL Comtech EF Data products and
consists of only the following OID:
Name: comtechEFData
Type: MODULE-IDENTITY
OID: 1.3.6.1.4.1.6247
Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtechEFData(6247)
Module: ComtechEFData
MIB file for the optional IP Module consists of all of the OIDs for management of the
IP functions
MIB file consists of all of the OIDs for management of the CDM-570/570L modem
functions
Trap MIB file is provided for SNMPv1 traps common for base modems.
CDM-570L MIB file consists of all of the OIDs for management of the BUC and LNB.
CDM-570L Trap MIB file is provided for BUC and LNB SNMPv1 traps
MIB file consists of all the OIDs for management of the CSAT-5060 Transceiver
connected to the CDM-570 modem through FSK.
MIB file consists of all the OIDs for management of the KST-2000A/B Transceiver
connected to the CDM-570 modem through FSK.
REM ETHERNET.
6–5
Revision 12
MN/CDM570L.IOM
