CDM-570/570L Satellite Modem with Optional IP Module
Ethernet IP Module - CLI and Telnet Operation
14.2.8

Satellite Modem Page

Activate the Satellite Modem page by selecting Satellite Modem Configuration from the Main
Menu page.
The Satellite Modem page contains the following options/fields:
Selection
Modem Type
Configuration
Monitor
Information
Utilities

Figure 14-24. Modem Parameters Page

Entry Description
[RO] Identifies the Modem type – CDM-570 or CDM-570L.
C Displays the Modem Configuration page.
M Displays the Modem Monitor page.
I Displays the Modem Information page.
U Displays the Modem Utilities page.
14–37
Revision 12
MN/CDM570L.IOM
