CDM-570/570L Satellite Modem with Optional IP Module
Front Panel Operation
If, however, the selected location already contains data, the time and date stamp of the previously
stored configuration displays for identification purposes, as per the following example:
Save Config to Loc: 9
11:10:29 23/12/03 (▲ ▼)
If the selected location does not contain a previously stored configuration, the screen appears as
follows:
Your Configuration has
been Saved to Loc 9 (ENT)
Press ENTER or CLEAR to return to the previous menu.
If, however, the selected location does contain a previously stored configuration, you will be first
prompted to overwrite the location. The screen appears as follows:
Loc 9 Contains Data!
Overwrite? NO YES
◄ ►
Use the arrow keys to select No or Yes, and then press ENTER. Selecting Yes overwrites the
selected location's existing configuration.
Once a modem configuration has been properly saved, press ENTER or CLEAR to return to the
previous menu.
5.2.2.5.2

Save/Load Configuration: Load

Use the
▲ ▼
loaded, and then press ENTER. Locations 0 through 9 are available.
Using Location 9 for this example:
If Load is selected and a configuration is stored at the chosen location, the time and date stamp of
the previously stored configuration displays for identification purposes, as per the following
example:
Load Config from Loc: 9
11:10:29 23/12/03 (▲ ▼)
the selected location contains no configuration data, the screen appears as follows:
If, however,
Load Config from Loc 9
Empty
Use the
▲ ▼
Location 8), and then press ENTER. If the newly selected location contains valid data, the
display appears as follows:
(◄ ►)
arrow keys to select the location from where the current configuration is to be
(▲ ▼)
arrow keys to select another location from which to load a configuration (e.g.,
5–45
Revision 12
MN/CDM570L.IOM
