CDM-570/570L Satellite Modem with Optional IP Module
Ethernet IP Module - CLI and Telnet Operation
Selection
Rx Demodulation
Rx Spectrum Inversion
Rx Data Inversion
Rx Descrambling
Rx Acquisition Range
(Sweep Width)
Alarm Point
E /N
b 0
Rx Buffer Size
Recenter Rx Buffer
Entry Description
M Sets receive demodulation type
1 – BPSK
2 – QPSK
3 – OQPSK
4 – 8-PSK
5 – 16-QAM
6 – 8-QAM
1 – Normal
U
2 – Inverted
1 – Normal
I
2 – Inverted
B 1 – Off
2 – On-Default
3 – On-IESS-315
W Valid ranges are from 0 to 200 kHz
(1 to 32HKz if symbol rate < 625Ksymbol)
P Valid ranges are from 0.1 to 16.0
F 1 – Disabled
2 – +/-_1024_bits
3 – +/-_2048_bits
4 – +/-_4096_bits
5 – +/-_8192_bits
6 – +/-_16384_bits
7 – +/-_32768_bits
C Recenters the Plesiochronous/Doppler Buffer.
14–42
Revision 12
MN/CDM570L.IOM
