CDM-570 Satellite Modem with Optional IP Module
Base Modem Web Server Interface
7.2.2 CDM-570 Menu Tree and Splash Page
The options available through the CDM-570 Base Modem HTTP Interface are illustrated via the
following menu tree:
Home
Home Access
Contact Remote
Support
Beyond the top-level row of navigation tabs (shown in blue), the diagram illustrates the available
nested hyperlinks (shown in grey) that affords more specific functionality.
Admin Config Mdm
Modem
Modem Utilities
AUPC

Figure 7-1. CDM-570 "Splash" page

Stats
Modem Status
Modem Logs
7–3
Revision 12
MN/CDM570L.IOM
ODU* Maint
Config Unit Info
Status
Utilities
