Packet Structure

Start of Packet

Target Address

<
ASCII code 60
(1 character)
Example: <0135/TFQ=1949.2345{CR}
Start of Packet Target Address
>
ASCII code 62
(1 character)
Example: >0654/RSW=32{CR}{LF}
D.5.1 Start of Packet
Controller-to-Target: This is the character '<' (ASCII code 60).
Target-to-Controller: This is the character '>' (ASCII code 62).
Because this is used to provide a reliable indication of the start of packet, these two characters may not appear anywhere else within the
body of the message.
D.5.2 Target Address
Up to 9999 devices can be uniquely addressed. In EIA-232 applications this value is set to 0. In EIA-485 applications, the permissible
range of values is 1 to 9999. It is programmed into a Target unit using the front panel keypad.
Address Delimiter
/
ASCII code 47
(4 characters) (1 character)
Address Delimiter
/
ASCII code 47
(4 characters) (1 character)
Controller-to-Target
Instruction Code Code Qualifier
= or ?
ASCII codes 61 or 63
(3 characters) (1 character)
Target-to-Controller
Instruction Code Code Qualifier
=, ?, !, or *
ASCII codes
61, 63, 33, or 42
(3 characters) (1 character)
D–3
Revision 12
MN/CDM570L.IOM
Optional Arguments End of Packet
Carriage Return
ASCII code 13
(n characters) (1 character)
Optional Arguments End of Packet
Carriage Return, Line
Feed
ASCII codes 13,10
(From 0 to n
characters) (2 characters)
