Chapter 13. ETHERNET IP

13.1 Introduction

The CDM-570/570L's optional Ethernet IP Module Interface makes the CDM-570/570L a high-
performance, low-cost, IP-centric satellite modem that is well-suited for closed network Single
Channel Per Carrier (SCPC) links. It is also ideal for many VSAT applications.
The CDM-570/570L, when equipped with the optional Ethernet IP Module V1/MP-550 or
V2/MPP-70 Interface, can also be used in a Vipersat satellite bandwidth management system
(VMS). For specific information about CDM-570/570L IP Module operation when deployed in a
Vipersat system, see adjunct Comtech EF Data publication MN/22125 – Vipersat
CDM-570/570L Satellite Network Modem Router User Guide.

13.2 Major Assemblies

Assembly
PL/10235-1
PL-0001216

13.3 Ethernet IP Module Standard Features

•
10/100BaseT Ethernet Interface
•
Powerful Network Management:
o Front Panel operation for complete product management
o HTTP Interface for complete product management
o SNMP with public and private MIB
o Console Port interface for local network management
o Telnet interface for remote product M&C
MODULE INTERFACE
Description
Ethernet IP Module V1/MPP-50
Ethernet IP Module V2/MPP-70
13–1
