CDM-570/570L Satellite Modem with Optional IP Module
Ethernet IP Module - CLI and Telnet Operation
14.2.11.2.1.1
Activate the Filter/Drop Statistics page from the Statistics for IP Routing/EasyConnect page.
This page displays counts of the number of packets filtered or dropped in the IP Module.
The Filter/Drop Statistics page contains the following options/fields:
Selection
Filtered – Boot
Filtered – Flow Descriptor
Filtered – Unknown
Reason Code

Filter/Drop Statistics Page

Figure 14-39. Filter/Drop Statistics page

Entry Description
[RO]
Packets are filtered while booting.
1. Packet are Filtered due to a Multicast packet classified as UNICAST packet.
2. Packets are filtered due to offline modem receiving packet from WAN port.
Packets dropping due to reasons not listed here.
14–55
Revision 12
MN/CDM570L.IOM
