CDM-570/570L Satellite Modem with Optional IP Module
Appendix L
L.5

ODU Operations via the CDM-570L IP Module HTTP Interface

L.5.1 ODU-Accessible IP Module HTTP Interface – Overview
As with the CDM-570L Base Modem HTTP Interface, the optional IP Module's
embedded HTTP Interface provides an easy to use application to configure and
monitor all aspects of a BUC or LNB. For a complete overview of the features
for this interface, see Sect 13.6. IP Module HTTP Interface.
L.5.1.1 IP Module HTTP Interface – Home Page and Menu Tree
Once a web browser is opened and a
valid IP address has been entered,
the CDM-570L IP Module HTTP
Interface "splash" page is displayed:
The options available through this interface are illustrated with the following menu tree. Operations
not specific to the ODU appear dimmed in this diagram and are explicitly defined in Section 13.6.
IP Module HTTP Interface:
Home
Home
Contact
Support
Logoff
Modem
Admin
Summary Modem
Mode Utilities
Access Status
Features Logs
BUC
Remote
LNB
Encryption
IP
Interface
Routes
Multicast
QoS Mode
QoS Compression
ARP
VLAN
IGMP
Redundancy
L–15
Revision 12
MN/CDM570L.IOM
Stats Maint
Ethernet Unit Info
Routes Operations
QoS* Save
1
WAN Reboot
