CDM-570/570L Satellite Modem with Optional IP Module
Ethernet IP Module Interface
13.3.10.1

Combined Working Mode

In order greatly simply the configuration complexity, the working modes operation of modem
have been centralized in the single Working Mode configuration parameter, which in turn offer
the following functional parameters:
Mode Selection
Managed Switch
Router-Hub
Router-Remote
Router-Point to Point
Vipersat Router-Hub
Vipersat Router-Hub Expansion
Vipersat Router-Remote
Vipersat Router-Remote Expansion
The Vipersat "Unit Role" and "Expansion Role" parameters are not read-only.
Function
Managed switch with support for VLAN as well as advanced features
such as QoS, Header Compression and Payload Compression.
Primarily intended for operation in a point-to-point topology.
Hub side router in a Point-to-Multipoint network.
Allows Sat-to-sat
Remote Router in a Point-to-Multipoint network. Packets from the WAN
are not allowed to be sent to the WAN. No longer requires HDLC
receive addresses to be configured.
Point-to-Point router in Point-to-Point configurations.
Hub router in a Vipersat Network
Hub Expansion router in a Vipersat Network
Remote router in a Vipersat Network
Remote Expansion Router in a Vipersat Network.
13–7
Revision 12
MN/CDM570L.IOM
