CDM-570/570L Satellite Modem with Optional IP Module
Ethernet IP Module Interface
13.4.4

Payload Compression

Traffic optimization through Payload Compression is an optional feature of the IP Module.
Note the following:
•
FAST feature to upgrade
•
Uses AHA chip
•
Compression algorithm applied to all data (HDLC header excluded)
•
Compression statistics are fed back to QoS in order to maximize WAN utilization while
maintaining priority, jitter and latency
•
1024 simultaneous compression sessions to maximize compression across multiple
distinct traffic flows
•
Compression algorithm not applied to RTP streams because this traffic is already
compressed and would only INCREASE the sat bandwidth if compressed again
•
Additional statistics have been added to the compression statistics menu in order to
provide feedback on the compression efficiency that has been achieved
•
Payload Compression is selectable on a per route basis

13.4.4.1 ADLC vs. LZS Compression Comparison

These numbers have been generated by using an internally created test program. This program
takes the target benchmark files and splits the files into payload size chunks and compresses each
chunk in a separate invocation of the compression algorithm. This is important to note because
most compression algorithms are applied to the entire file data set as a single invocation of the
compression algorithm which is easier for other types of compression algorithms (LZS, GZIP in
specific). This, of course, does not apply to streamed packet data across an IP network (FTP
transfer, for example).
Payload
Algorithm
size
1472
1000
ADLC
1472
1000
File Set Ratio
1.76
1.76
Calgary
500 1.77
100 2.09
1.71
1.72
Canterbury
500 1.74
100 2.04
Payload
Algorithm
LZS
13–10
Revision 12
MN/CDM570L.IOM
File Set Ratio
size
1472 1.66
1000 1.66
Calgary
500 1.68
100 1.97
1472 1.61
1000 1.62
Canterbury
500 1.63
100 1.91
