CDM-570/570L Satellite Modem with Optional IP Module
Appendix K
K.3.3

SELECT: (Main) Menu

SELECT: Config Test Info
Monitor Save/Ld Util ODU
The table that follows identifies the commands comprising the CDM-570 main menu, and the
content section in this manual where explicit information may be referenced, either in this
appendix or in Chapter 5. FRONT PANEL OPERATION:
Menu Branch
(For more info, see...)
Config
(Chapter Sect. 5.2.2.1)
Test
(Chapter Sect. 5.2.2.3)
Info
(Chapter Sect. 5.2.2.4)
Monitor
(Chapter Sect. 5.2.2.2)
Save/Ld
(Chapter Sect. 5.2.2.5)
Util
(Chapter Sect. 5.2.2.6)
ODU
(Appendix K.3.2:
K.3.2.1 for CSAT-5060
K.3.2.2 for KST-2000A/B)
For ODU operation, use the
K.3.3.1 (SELECT:) ODU
Transceiver Control:
Disable Enable (◄ ►,ENT)
◄ ►
Use the
following:
Disable
Enable
Once the FSK link to the ODU is enabled, the CDM-570 senses the active ODU model and
automatically adjusts the front panel menu selections specific to that product. Sections K.3.3.1.1
and K.3.3.1.2 address front panel operation functionality as it is adapts to CSAT-5060 or
Description
Used to fully configure the modem.
Used to invoke one of several test modes (loopbacks, for example).
(Information) Used to view information on the modem, without having to go
into configuration screens.
Used to monitor the alarm status of the modem, to view the log of stored
events, and to display the Receive Parameters screen.
(Save/Load) Used to save and to retrieve up to 10 different modem
configurations.
(Utility) Used to perform miscellaneous functions, such as setting the Real-time
clock, adjusting the display brightness, etc.
(Outdoor Unit) Used to monitor and control a Comtech EF Data RF
Transceiver (CSAT-5060 or KST-2000A/B), if connected.
◄ ► arrow keys to select ODU, and then press ENTER.
arrow keys to select Disable or Enable, and then press ENTER. Note the
This menu item turns OFF the FSK link to the ODU
This menu item turns ON the FSK link to the ODU
