Comtech EF Data CDM-570 Installation And Operation Manual page 470

CDM-570/570L Satellite Modem with Optional IP Module
Appendix K
K.3.3.1.1.1.1 COMMON 'ODU SELECT' SUBMENU
(ODU: Enable) Standalone
(ODU: Enable) 1:1
(ODU: Enable) 1:1
ODU SELECT: Config
Monitor Alarms (
Use the ◄ ► arrow keys to select Config, Info, Monitor, or Alarms, and then press ENTER.
K.3.3.1.1.1.1.1 ODU SELECT: Config
ODU CONFIG: Transmitter
Receiver
Use the ◄ ► arrow keys to select Transmitter, Receiver, or Misc,and then press ENTER.
(ODU SELECT) ODU CONFIG: Transmitter
ODU TX: Frequency Atten
Amplifier Mute Slope
Use the ◄ ►
press ENTER.
(ODU SELECT) ODU CONFIG: ODU TX
ODU Tx Frequency:
5912.5 MHz (
To edit the transmit frequency: First, use the
then use the
(ODU SELECT) ODU CONFIG: ODU TX
ODU Tx Attenuation:
15.00 dB
To edit the transmit attenuation: First, use the
then use the
(ODU SELECT) ODU CONFIG: ODU TX
ODU Tx Amp State:
On
Use the
CSAT#1
CSAT#2
Info
◄ ►
,ENT)
◄ ►
Misc ( ,ENT)
◄ ►
arrow keys to select Frequency, Atten, Amplifier, Mute, or Slope, and then
◄ ►,▲ ▼,
▲ ▼
arrow keys to change the value of that digit. Press ENTER when done.
(◄ ►,▲ ▼,ENT)
▲ ▼ arrow keys to change the value of that digit. Press ENTER when done.
Off (◄ ►,ENT)
◄ ►
arrow keys to select On or Off, and then press ENTER.
Frequency
ENT)
◄ ► arrow keys to select a digit to edit, and
Atten (Attenuation)
◄ ► arrow keys to select a digit to edit, and
Amplifier
K–8
Revision 12
MN/CDM570L.IOM
