CDM-570/570L Satellite Modem with Optional IP Module
Appendix L
L.3.3.1.2.1.1 (CONFIG: ODU (Outdoor Unit)) BUC: M&C-FSK
BUC M&C(FSK): FSK-Comms
Address Tx-On/Off
When an FSK-capable BUC is employed, use this menu to define, control and monitor the FSK
setup. Use the ◄ ► arrow keys to select Comms, Address, or Tx-On/Off. Press ENTER when
done
(CONFIG: ODU (Outdoor Unit)) BUC: BUC M&C (FSK)
BUC M&C FSK Comms:
On Off
Use the ◄ ► arrow keys to select FSK communications between the modem and BUC as On or
Off. Press ENTER when done.
(CONFIG: ODU (Outdoor Unit)) BUC: BUC M&C (FSK)
BUC FSK Address: 01
To enter the logical address of the BUC: Use the ▲ ▼ arrow keys to edit the value of the
address – the valid range is from 01 to 15 – and then press ENTER.
(CONFIG: ODU (Outdoor Unit)) BUC: BUC M&C (FSK)
BUC RF Output:
On Off
Use the ◄ ► arrow keys to select the BUC RF Output as On or Off. Press ENTER when
done.
L.3.3.1.2.1.2 (CONFIG: ODU (Outdoor Unit)) BUC: DC-Power
BUC DC Power:
On Off
Use the ◄ ► arrow keys to select the BUC DC Power as On or Off. Press ENTER when done.
L.3.3.1.2.1.3 (CONFIG: ODU (Outdoor Unit)) BUC: 10MHz
BUC 10MHz Reference:
On Off
Use the ◄ ► arrow keys to select rgw BUC 10 MHx Frequency Reference as On or Off. Press
ENTER when done.
(◄ ►)
(◄ ►,ENTER)
(▲ ▼,ENTER)
(◄ ►,ENTER)
(◄ ►,ENTER)
(◄ ►,ENTER)
L–6
Revision 12
MN/CDM570L.IOM
Comms
Address
TX-On/Off
