Comtech EF Data CDM-570 Installation And Operation Manual page 275

CDM-570/570L Satellite Modem with Optional IP Module
Ethernet IP Module - CLI and Telnet Operation
Selection
Working Mode
Managed Switch
Multicast Option
(For Modem Firmware
Ver. 1.5.4 and later; was
"easyConnect Multicast
Option" for Modem
Firmware Ver. 1.5.3.6 and
earlier)
Header comp refresh rate
(in pkts) for UDP/RTP1
Header comp refresh rate
(in pkts) for UDP
Header comp refresh rate
(in pkts) for all others
Payload comp refresh
rate (in pkts)
Telnet Timeout
Entry Description
W*
Sets the Working Mode.
-or- *For IP Module V1 Firmware Ver. 1.7.# and later / IP Module V2
Firmware Ver. 2.2.# and later:
C**
•
Managed Switch
•
Router – Hub
•
Router – Remote
•
Router – Point to Point
** For IP Module Firmware Ver. 1.6.# and earlier / IP Module V2
Firmware Ver. 2.1.# and earlier:
•
Router – Small Network
•
Router – Large Network
•
Router – Point to Point
•
Managed Switch
See Chapter 13 for additional information.
Working Mode is disabled when Brouter Mode VLAN
Filtering is enabled. If selection is attempted while
configured as such, the following error message displays:
"Can't change Modem Working Mode when
Brouter VLAN Filter is Enabled"
If both units have this feature enabled, when unit is running in Managed
E
Switch mode, Multicast is only forwarded across link.
H
Allows for the adjustment of how often to send a full header of this type of
U
traffic when Header Compression is enabled.
O
Allows for the adjustment of how often to send a full payload when Payload
Q
Compression is enabled.
Determines how many minutes (1-60) of Telnet inactivity before the Telnet
T
session is automatically terminated.
14–5
Revision 12
MN/CDM570L.IOM
